Fill‑Gel 600LV is a one‑component fully‑cured silicone thermal gel with thermal conductivity of 6.0W/m・K, no mixing or post‑curing required. It features high thixotropy and flexibility, suitable for large‑tolerance gaps and multi‑heat‑source components sharing one heat sink. High conformability enables low‑stress application to protect sensitive parts. Formulated for low‑volatility, low‑siloxane and low oil‑bleeding performance with anti‑slump and anti‑cracking properties, it is ideal for optical devices and LED lighting with strict volatile‑limit requirements. It supports automatic dispensing and is rework‑friendly for field repair. Working temperature:‑50℃ ~ 200℃, UL94 V‑0 flammability rating.

It is widely used for chassis and related cooling modules, LED lighting, smart terminals, mobile phones, tablet computers, communication equipment, optical modules, SSD and camera modules.

Light grey color; density 3.4g/cm³; flow rate 18g/min (30cc EFD tube, 2.5mm nozzle, 90psi,60s); outgassing TML 0.2%, CVCM 0.02%; siloxane content ∑D₃‑D₁₀ ＜100 ppm; minimum bondline thickness ＜0.13mm; thermal conductivity 6.0W/m・K; dielectric strength ≥6kV/mm; volume resistivity ≥1.0×10¹³Ω・cm.

Package options: 30cc, 50cc, 100cc, 180cc, 300cc, 600cc cartridge, 5‑gallon pail. Storage: keep sealed, 0‑35℃, ≤65% RH; shelf‑life 12 months from the packing date. Do not ingest; keep away from children and combustion sources; refer to MSDS for full guidance.
